Timken® Fafnir Insert Ball Bearings
GY Series — Shaft Guard Technology (SGT)
Timken Fafnir GY-series insert bearings with Shaft Guard Technology (SGT) feature a patented polymer sleeve between the locking collar and the shaft surface, preventing the metal-to-metal contact that causes shaft damage during installation and operation. When the bearing needs replacement, the shaft is unmarred — no filing, no polishing, no shaft replacement. This translates directly to faster turnarounds and lower maintenance costs.
The SGT sleeve also dampens vibration transmission between the collar and shaft, reducing noise in fan, blower, and conveyor applications. Available with eccentric collar locking and triple-lip seals for dirty, wet, or high-contamination environments. Spherical O.D. fits standard self-aligning housed units (pillow blocks, flanged units, take-ups).
Timken (NYSE: TKR) acquired the Fafnir bearing brand in 2003, combining Fafnir’s 90+ year legacy in mounted ball bearing technology with Timken’s global engineering expertise.
| SKU | Shaft Size | Locking | Seal Type | Weight |
|---|---|---|---|---|
| GY Series — Shaft Guard Technology (17 sizes) | ||||
| GY1012KRRB SGT | 3/4" - 0.75in - 19.05mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 0.380 lbs |
| GY1014KRRB SGT | 7/8" - 0.88in - 22.23mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 0.580 lbs |
| GY1015KRRB SGT | 15/16" - 0.94in - 23.81mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 0.530 lbs |
| GY1100KRRB SGT | 1" - 1.00in - 25.40mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 0.500 lbs |
| GY1102KRRB SGT | 1-1/8" - 1.13in - 28.57mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 0.716 lbs |
| GY1104KRRB SGT | 1-1/4" - 1.25in - 31.75mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 1.172 lbs |
| GY1106KRRB SGT | 1-3/8" - 1.38in - 34.92mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 1.260 lbs |
| GY1107KRRB SGT | 1-7/16" - 1.44in - 36.51mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 1.200 lbs |
| GY1108KRRB SGT | 1-1/2" - 1.50in - 38.10mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 1.452 lbs |
| GY1110KRRB SGT | 1-5/8" - 1.63in - 41.27mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 1.980 lbs |
| GY1111KRRB SGT | 1-11/16" - 1.69in - 42.86mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 1.870 lbs |
| GY1112KRRB SGT | 1-3/4" - 1.75in - 44.45mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 1.590 lbs |
| GY1115KRRB SGT | 1-15/16" - 1.94in - 49.21mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 2.180 lbs |
| GY1200KRRB SGT | 2" - 2.00in - 50.80mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 2.650 lbs |
| GY1203KRRB SGT | 2-3/16" - 2.19in - 55.56mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 2.278 lbs |
| GY1204KRRB SGT | 2-1/4" - 2.25in - 57.15mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 4.300 lbs |
| GY1207KRRB SGT | 2-7/16" - 2.44in - 61.91mm | Set Screw | Shaft Guard + Heavy Contact Seal (KRRB) | 3.058 lbs |
Where Shaft Guard Technology Bearings Excel
- Agricultural Equipment — disc harrows, planters, combines, grain augers where shaft damage from spinning inserts is common
- Conveyor Systems — belt conveyors, screw conveyors, material handling where shaft replacement costs more than the bearing
- Food & Beverage — washdown environments where corrosion increases fretting risk
- Mining & Aggregate — high-vibration screening and crushing equipment
- General Industrial — any application where you’ve experienced shaft wear under insert bearings
Why Shaft Guard? Standard insert bearings can spin on the shaft during overload, machining grooves into the surface. Shaft Guard Technology uses a patented inner ring design that grips without damaging — protecting your most expensive component.
1 All dimensions follow the Lambear tri-format: Imperial fraction – Decimal inches – Metric (mm).
2 Housed units sold separately. Match insert series and shaft size to your housing.
